Wiring Examples

Process Input Signal Wiring Diagrams (V)

4 WIRE CONNECTION WITH EXTERNAL EXCITATION
DPM2
1
7
+V
COM.
3 WIRE CONNECTION WITH EXTERNAL EXCITATION
DPM2
1 7
+V
COM.
User Manual - DPM2 Series Process Panel Meters
TRANSDUCER
0-10V
0-200V
+OUT -OUT -EXC. +EXC.
- +
EXC.
TRANSDUCER
0-10V
0-200V
+OUT -OUT +EXC.
- +
EXC.
DPM2 Process User Manual, 1st Edition
4 WIRE CONNECTION WITH EXCITATION SUPPLIED BY THE DPM2
DPM2
1 7
6
+V
+EXC.
COM.
3 WIRE CONNECTION WITH EXCITATION SUPPLIED BY THE DPM2
DPM2
1
6 7
+V
+EXC.
COM.
TRANSDUCER
0-10V
0-200V
+OUT -OUT -EXC. +EXC.
TRANSDUCER
0-10V
0-200V
+OUT -OUT +EXC.
