Pt100 and Pt1000 Sensor Input Wiring Diagrams

DPM2
1 2 4
RTD B Pt100
RTD A
RTD B

Thermocouple J, K, T and N Input Wiring Diagram

Resistance Input Wiring Diagram (Ω)
DPM2
1 3
50kΩ
COM.
Note: Do not perform measurements with resistance subjected to external voltage, since it
may interfere in the measurement, alter the reading and even cause serious damages to this
unit.

Relay Output Wiring

RELAY 2
NO
4
CM
5
6
NC
8A/250V MAX.
Important: To guarantee electrical safety according to EN 61010-1 a protective 8A/250V
external fuse must be installed.
User Manual - DPM2 Series Process Panel Meters
Pt100 SENSOR
DPM2
1 2
+TC
-TC
50kΩ MAX.
RELAY 1
NO
1
CM
2
3
NC
DPM2 Process User Manual, 1st Edition
DPM2
1 2
RTD A
RTD B
J,K,T,N
-
+
DPM2
1 2
10kΩ
COM.
Pt1000 SENSOR
10kΩ MAX.
11
