Maintenance
To ensure instrument accuracy, it is recommended to check its performance according to the
technical specifications listed in this manual.
For front cover cleaning, just wipe with a damp cloth and neutral soap product. DO NOT USE
SOLVENTS!
Technical Support
We strive to make our manuals the best in the industry. We rely on your feedback to let us
know if we are reaching our goal. If you cannot find the solution to your particular application,
or, if for any reason you need technical assistance, please call us at:
Our technical support group will work with you to answer your questions. They are available
Monday through Friday from 9:00 A.M. to 6:00 P.M. Eastern Time. We also encourage you
to visit our web site where you can find technical and non-technical information about our
products and our company.
Agency Approvals
Description
The ProSense DPM2 series offers a simple, low cost digital display of analog process signals,
temperature in either Fahrenheit or Celsius from RTD or Thermocouple temperature sensors,
or potentiometer inputs. The 4-digit 14mm character height red LED display is easily scaled
into any engineering units from -9999 to 9999 with a selectable decimal point location. The
DPM2L offers a larger 20mm character height scaled from -1999 to 9999. Two point direct
or reverse acting linear scaling values can be entered manually or by introducing actual sensed
process values in Teach mode. Temperature inputs are pre-configured for fixed temperature
ranges based on the type of temperature sensor and can be displayed with 1 or 0.1 degree
of resolution. One model includes two SPDT relay outputs that can be set to activate on
an increasing or decreasing input signal with hysteresis or time delay operation. The meter
is powered from an external wide range AC or DC power supply and provides 24VDC for
external sensor excitation. The 1/8 DIN housing is easy to install in a panel and the meter
face has an IP65 rating. Configuration parameters can be totally or selectively locked out to
prevent unauthorized or accidental changes to the meter's operation. Additionally, the DPM2
meters include memory and reset of minimum and maximum display values. ProSense digital
panel meters are backed by a 3 year warranty.
User Manual - DPM2 Series Process Panel Meters
1-800-633-0405
www.AutomationDirect.com
DPM2 Process User Manual, 1st Edition
5
