Irrigation

Multi-stage irrigation controls operate watering stages in a sequential fashion. Each stage may have a
unique irrigation duration and output assignment (output channels do not need to be sequential.) Once all
of the stages have completed, they can be repeated at speci c intervals for a speci c count.
Irrigation stages can coordinate with an irrigation pump or main supply valve, and can operate a drain valve
output for ood tables between stages.
Irrigation may be triggered based on time of day when the funciton is enabled, or by moisture level if a
moisture sensor is connected.
Irrigation Stages
To con gure irrigation stages:
1. Press the [ + ADD STAGE ] button (1) and a new stage will be created.
3. Enter a time duration for the stage to irrigate in the STAGE FEED TIME eld (4).
3. Select the device and output of the stage to operate the attached irrigation valve (5).
To edit a stage, select the stage number from the stage drop-down (3).
5
6
1. Add Stage
2. Remove Stage
3. Stage
4. Stage Feed Time
5. Stage Output
6. Repeat Settings
60
3 4
Adds a new irrigation stage to the function setting.
Deletes the currently seleted stage from the function settings.
Select the stage number to edit or remove.
Duration to run the stage output for irrigation.
Stage output device and channel (irrigation valve.)
If the irrigation is to repeat, set the number and delay between repeat cycles.
