Control Groups
Controls functions are sorted by "control groups. " Each control group that is created gets it's own "work
space" in which to add, edit and monitor control functions.
Control groups are often modeled after the physical spaces they are controlling (room 1, room 2, etc.) but
can also be created based on any type of organization that makes sense for the application.
At least one control group is required.
NOTE: Controls are executed in the order that they are listed in the group list.
Control groups are managed by the workspace bar at the top of the controls page:
1. Run/Pause
Open a dialog to place the group into run or pause mode.
2. Current Group
Select which control group workspace to show.
3. Rename Group
Open a dialog to rename the current control group.
4. Add Group
Open a dialog to add a new control group to the system.
5. Move Group
Open a dialog to move the current control group in the list order.
6. Delete Group
Open a dialog to delete the current group and all of it's control functions.
Controls Workspace
Control functions in each control group are edited and monitored in the workspace.
1. Toolbar Functions
2. Workspace Functions
1
2
38
1
The toolbar is used to add new control functions to a workspace.
Workspace functions show the logic in the workspace.
Click the workspace function to edit the settings.
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
2
3
4
5
6
