Graph Window
Historical graph data can be analyzed on-screen to review:
• Minimum and Maximum (High/Low) sensor readings
• Point data with 'cursor' selection
• Graph history
To open the graph window, touch on a graph pane in the monitor page of a device.
A maximum of 1440 points are shown on the graph pane.
Graph data is stored on the system in .csv format for export by USB or email; see the "Files" section of this
manual. To set the data logging interval, see the "device management" tab.
6
5
1. Exit Button
Press to close the graph window.
2. Cursor
Touch on the graph display to show cursor data (newest data page only.)
3. Date
Beginning and end dates of the data on the chart.
4. Fwd/Back
Page Forward/Backward buttons to move through histortical data.
5. High/Low
High/Low value on the current graph page.
6. Cursor Data
Data at the point shown by the cursor line when the chart area is touched.
Only on newest data page.
16
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
