Agrowtek GrowControl GCX Instruction Manual page 66

pH & ORP Pumps
pH and ORP pumps must all be on the same dosing pump device (but may be assigned to individual pump
heads.) pH and ORP dosing is performed at a speci c ow rate (ml/min) until the target value is achieved. pH
and ORP dosing can be disabled while nutrient dosing is being performed so that it occurs after the nutrient
dosing as opposed to simultaneously.
To con gure pH dosing, select a dosing pump device (1) and then enable the pH Up (2) and/or pH Down (3)
switch options. When enabled, select the pump head (5) on the pump device to use and enter a ow rate (6)
to dose at.
1
2
3
4
1. Dosing Pump Device
2. pH Up Dosing
3. pH Down Dosing
4. ORP Dosing
5. Pump Head
6. Flow Rate
7. Disable Switch
Discrete Output
A discrete output can be activated when ever the dosing function is operating in order to control a mixing
pump, operate a valve, or run some other device while the dosing is running.
1
2
1. Enable Output
2. Output Device Settings
66
Select the device that has the desired chemical pump heads on it.
Enable the switch to show the con guration settings.
When enabled, the dosing pump head and ow rate settings are shown.
Enable the switch for ORP dosing settings.
Select an available pump head on the pump device for the dosing mode.
Flow rate for the respective pump head to dose at.
Disables the pH/ORP dosing when the nutrient dosing is active.
Enable the discrete output to show the output device settings.
Select a device and output to operate when the dosing function is active.
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
7
5
6
