Devices Page
The devices page displays all of the relevant data pertaining to GrowNET™ devices that are connected to
the system, and manages all of their properties including reference names, alarm settings, calibration and
manual operation / overrides.
4
1. Devices Menu Bar Change between the different pages in the devices screen.
2. Page Title Bar
Displays the title of the current page. A help [?] button is located on most title bars.
3. Page Area
Area to display the selected menu bar page; the device monitor page is shown.
4. Device List
The device list shows the name and status of each device.
Select the device to monitor the device or edit the device properties.
Devices Menu Bar
The devices menu bar selects between the monitoring page and, alarms, calibration and other device prop-
erties pages. The bar indicates which page is active by highlighting the icon green and darkening the back-
ground. Press the tabs to switch between the screen pages.
1
1. Monitor Page
Display historical data and manually operate control equipment.
2. Info Page
Con gure device and output names, report settings and search "where used. "
3. Alarms Page
For devices with alarm settings, con gure high/low alarm values.
4. Calibration Page
Standard calibration of sensors and dosing pump ow rates.
5. Manage Device
Device manufacturing info, address, sort order, out-of-service mode and more.
11
2
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
3
4
1
2
3
5
