Device Information

The device information page is where device names are managed and where devices can be con gured for
display in the report views on the home page.
Names
Device names and I/O names are used for more than just reference. Names are used when configuring con-
trol functions to assign sensors, outputs, inputs, pumps, etc. to the functions. If equipped with outputs or
analog inputs, each channel can be named for reference.
Where Used
To determine which control functions are assigned to use a speci c output, select the output from the drop-
down menu and press the where-used search button. This can aid in troubleshooting if a device is operating
in an unexpected fashion.
Device Location
To show the device in the home report view select a control group to associate it with, then check the box to
show it in the report.
1
2
3
4
5
6
1. Device Name Reference name for the GrowNET™ device.
2. Device Location Reference the device to a control group to display the device in the home report.
3. Show in Report Select to show the device in the home report display.
4. Output Select Select an output (or input) to search "where used" or edit the name.
5. Where Used Search where this output is used in the control functions.
6. Channel Name Output (or input) channel name; typically named for what is connected to the channel.
7. Save Button When highlighted Green, there are changes that are not saved.
Press the Save button to save the changes to system memory.
17
