Enabling Control Functions

Functions can be enabled in different ways in order to create either simple or complex logic.
The "Enable Mode" settings are found in every control function.
1. Disabled The setting is disabled and will not activate.
2. Enabled The setting is enabled and will activate by schedule and other function settings.
3. If Output... The setting is enabled if a selected output is on or off.
4. If Function The setting is enabled if a selected function status is true (active) or false (idle.)
If Output On/O
To coordinate a function with the status of another device, the setting can be con gured to be enabled only
if an output is currently on or currently off.
1. Press the [ IF OUTPUT ... ] button in the desired on or off mode.
The Enable Mode area will expand and the drop-down menus to select an output will be displayed.
2. Select an output device.
3. Select an output on the device.
The function setting will now only be enabled according to the status of the selected output.
This type of feature is useful for enabling or disable equipment in coordination. For example, it may be desir-
able to disable a CO2 control when the exhaust output is activated.
