Thermostat
Thermostat controls are used to operate heating or cooling equipment based on a temperature set point
and temperature sensor reading. A setpoint determines the target temperature and a "deadband" deter-
mines the allowed drift from the target before activating the thermostat to return the reading to the target.
Example uses:
• Heating / Cooling HVAC equipment
• Exhaust fans
• Chillers
• Floor heating
1
2
3
4
1. Mode
Cool: Function activates when temperature exceeds setpoint.
Heat: Function activates when temperature is below setpoint.
2. Sensor
Temperature sensor input to evaluate the set point against.
3. Setpoint
The target sensor value to achieve.
4. Deadband
The allowed drift from the target before taking action to return to the target.
5. Preview
A preview of the function settings.
NOTE
When configuring a thermostat on HVAC systems it is recommended to control the "heat" or "cool" output
from the thermostat function, then control the "fan" output with a off-delay count timer that is activated
from either the heat/cool output, or the thermostat control function. This will activate the fan with the heat
or cool signal and inlcude an off-delay retaining the fan on for a set time after the heat/cool signal.
See the "Programming" section for more details.
50
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
