Agrowtek GrowControl GCX Instruction Manual page 43

Function Header
The function header is shown at the top of the function editor window.
1. Show in Report If checked the control function status will be shown on the home page report.
2. Function Name Press the [ X ] button to delete the name or press the text eld to edit the name.
The name eld must not be empty or the changes to the control function can not be saved.
3. Delete Function Open a dialog to delete the current control function from the workspace.
4. Save Settings Press the save button to save the changes to the system memory.
The save button will be highlighted green when settings on the page have changed.
5. Exit Editor Closes the editor dialog and returns to the workspace.
If changes have been made and are not saved before exiting they will be lost.
Function Settings List
The function settings list is used to select the settings to edit, and can also add, copy and delete settings
from the function. If there are con icting settings, the last setting will be the one executed by the system.
1. Delete Delete the selected setting from the function.
2. Copy Copy the selected setting to a new setting.
3. Add Add a new blank setting to the function.
4. Setting List List of all settings in the function.
43
1
4
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
2
1 2 3
3 4 5
