Function Order
Function order dictates priority of commands. Controls are executed in the order that they are shown in the
workspace beginning at the top left, going across to the right and beginning at the left again on the next
line. If two functions have con icting aims then the function that is executed last will take the priority.
Re-arranging Functions
To move a function within a workspace, press and hold on the function icon's title text. The function will be
highlighted green; drag the function to the new location in the workspace then release.
Workspace Icons
Each function that is added to the workspace has it's own button icon in the workspace. The button icons
include information about the function and it's status.
1
2
1. Function Button Icon depicts the type of control function; see the tool bar for reference.
2. Function Name The function name (set by the user) is shown under the function button.
3. Function Status The status of each function is shown in the upper left with a colored dot:
Empty
Green
Yellow
Red
4. Analog Output If a function has an analog output, the priority output value is shown here.
5. Invalid Status An invalid or disabled function will show a red dot; this function is not active.
40
3 4 5
Function is valid but not active (idle.)
Function is active.
Function is paused (group or system paused.)
Function has invalid parameters or is disabled.
