Agrowtek GrowControl GCX Instruction Manual page 20

Dosing Pump Calibration
Dosing pumps may vary from the factory calibrated ow rate if uids are viscous or supply lines are long.
Operate the pump for 60 seconds and measure the output with a graduated cylinder. Enter the measured
quantity as the calibration value (mL/min) to set the true ow of the dosing pump.
1
2
3
1. Channel Select the sensor channel or pump head to calibrate.
2. Calibration Value Follow the prompts and enter the calibration value.
3. Prompts Instructions to follow for calibration.
4. Calibrate Button Press once the calibration value has been entered to save the value.
5. Reset Button Restores factory sensor calibration values.
MX Motor Position Calibration
In some cases it may be necessary to adjust the calibration of the MX controller's position to ensure it is ac-
curate in the MX controller. There are two methods for calibrationg the MX controller position:
• Manually operate the MX controller until it reaches 0% (closed) and the motor stops at the working limit.
• Set the position to a known value using the device calibration page.
20
