DEFINITY Communications System
DEFINITY High Speed Link
User´s Guide
Appendix D: Applications and Switch Administration
Generic 1 Administration

Station Administration

In this application, the two HSLs (extensions 2000 and 2001) are
administered identically on the Generic 1 and are done using the
Data Module form (Screen D-1). The administration of this form
is identical to that of an MPDM:
Type: PDM. For administrative purposes, the HSL is aliased
as a "PDM".
Connected to: DTE. To indicate that the HSL is connected to a
data terminal equipment (DTE).
Remote Loop-Around Test: Y. To indicate that the module
responds to loop-back commands from the switch.
If Data Privacy is required, the Class of Service (COS) should be
assigned to a class in which the Data Privacy feature is active. In
this example, COS 1 has Data Privacy and is therefore assigned to
this extension. The Class of Restriction (COR) should be set so
that each extension can access an SDN/SDDN trunk. In this
example, COR 1 has been established to access an SDN/SDDN
trunk.
DATA MODULE
Data Extension: 2000
Name: Video1
Connected to: DTE
ABBREVIATED DIALING
List1: _________
HOT LINE DESTINATION
Abbreviated Dialing Dial Code (from above list):
ASSIGNED MEMBERS
(Stations with a data extension button for this data module
Ext Name
1:
2:
Generic 1 HSL Station Administration
Page 1 of 1
Type: pdm Port:
COS: 1 COR:
Remote Loop-Around Test:
__
Ext Name
3:
4:
SCREEN D-1
Page D-11
__
1
Y
