Specifications

HEX70HDU-TX Transmitter
• Video Input Connectors:
• Video Output Connectors:
• RS-232 Serial Port:
1 x 3-pin phoenix connector
• TCP/IP Control:
1 x RJ45, female
• IR Input Ports:
2 x 3.5mm stereo jack
• IR Output Port:
1 x 3.5mm mono jack
• EDID: 4-pin DIP switch
• Product Upgrade:
1 x Micro USB, female
• Local Power Input:
1 x
• Casing Dimensions (W x H x D):
HEX70HDU-RX Receiver
• Video Input Connectors:
• Video Output Connectors:
• Audio Output Connectors:
• RS-232 Serial Port:
1 x 3-pin phoenix connector
• Relay Control:
2 x 3-pin Phoenix connectors
• IR Input Port:
1 x 3.5mm stereo jack
• IR Output Port:
1 x 3.5mm mono jack
• Product Upgrade: 1 x Micro USB, female
• Local Power Input:
1 x
• Casing Dimensions (W x H x D):
• Operating Temperature:
• Storage Temperature:
• Shipping Weight:
2.3kg
• Power Supply:
24V/5A DC
NOTE: Specifications are subject to change without notice. Weights and dimensions are approximate.

Package Contents

• 1 x HEX70HDU-TX
• 1 x HEX70HDU-RX
• 1 x 24V/5A DC Power Supply
• 1 x IR Emitter
• 1 x IR Receiver
• 1 x RS-232 Control Cable
• 2 x Mounting Kits
• 1 x Quick Reference Guide
Acknowledgements
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®)
in the United States and other countries.
contact:
support@blustream.com.au
1 x HDMI Type A, 19-pin, female; 1 x USB Type C; 1 x DisplayPort™
1 x HDBaseT™ RJ45 connector
24V/5A 4-PIN DIN connector
180mm x 23.5mm x 155mm
1 x HDMI Type A, 19-pin, female; 1 x HDBaseT™ RJ45 connector
1 x HDMI Type A, 19-pin, female
5-pin phoenix connector (2ch balanced / unbalanced analogue audio); 1 x RCA (S/PDIF)
24V/5A 4-PIN DIN connector
180mm x 23.5mm x 155mm
32°F to 104°F (-5°C to +55°C)
-4°F to 140°F (-25°C to +70°C)
|
