RS-232 Configuration and Telnet Commands
COMMAND ACTION
? Print Help Information
HELP Print Help Information
STATUS Print System Status And Port Status
INSTA Print All Inputs Status
OUTSTA Print Outputs Status
CTRLSTA Print All Controls Status
PON Set System Power On
POFF Set System Power Off
KEY ON/OFF Set System Key Control On Or Off
IR ON/OFF Set system IR Control On or Off
Set No Signal Delay Timeout To xxx
NOSIGDLY xxx
(Default 0s, Range From 0s To 1800s)
Reset System To Default Setting
RESET
(Type 'Yes' To Confirm, 'No' To Discard)
REBOOT Reboot System
POCOUT ON Set PoC Output On
POCOUT OFF Set PoC Output Off
COAX ON/OFF Set Coax Audio Out On Or Off
contact:
support@blustream.com.au
|
support@blustream-us.com
COMMAND ACTION
ANALOGUE ON/OFF Set Analogue Audio Out On Or Off
BALANCEDAUD ON Set Analogue Audio Out To Balanced
BALANCEDAUD OFF Set Analogue Audio Out To Unbalanced
TX SWITCH aa Set Transmitter Switching To aa
RX SWITCH aa Set Receiver Switching To aa
Set The Trigger Method x On Transmitter Input To
Perform System On
TX TRGON x
x = 1 - HDMI (5V)
x = 2 - HDMI (TMDS)
Set The Trigger Method x On Receiver Input To
Perform System On
RX TRGON x
x = 1 - HDMI (5V)
x = 2 - HDMI (TMDS)
Set Output From Input:yy
xx = 00 : All RX Outputs
xx = 01 : RX Output 1
OUT xx FR yy yy = 01 : TX HDMI Input
yy = 02 : TX USB-C Input
yy = 03 : TX DisplayPort Input
yy = 04 : RX HDMI Input
Set Input xx EDID To Default EDID zz (EDID Dip Switch
Must Be Switched To EDID Software)
xx = 00: Select All Input Port
xx = [01...04]: Select One Input Port
zz = 00: HDMI 1080p@60Hz, Audio 2CH PCM (default)
01: HDMI 1080p@60Hz, Audio 5.1CH DTS/DOLBY
02: HDMI 1080p@60Hz, Audio 7.1CH DTS/DOLBY/HD
03: HDMI 1080i@60Hz, Audio 2CH PCM
04: HDMI 1080i@60Hz, Audio 5.1CH DTS/DOLBY
05: HDMI 1080i@60Hz, Audio 7.1CH DTS/DOLBY/HD
06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
07: HDMI 1080p@60Hz/3D, Audio 5.1CH DTS/DOLBY
08: HDMI 1080p@60Hz/3D, Audio 7.1CH DTS/DOLBY/HD
09: HDMI 4K@30Hz 4:4:4, Audio 2CH PCM
10: HDMI 4K@30Hz 4:4:4, Audio 5.1CH DTS/DOLBY
EDID xx DF zz 11: HDMI 4K@30Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
12: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 2CH PCM
13: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 5.1CH
DTS/DOLBY
14: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 7.1CH
DTS/DOLBY/HD
15: HDMI 4K@60Hz 4:4:4, Audio 2CH PCM
16: HDMI 4K@60Hz 4:4:4, Audio 5.1CH DTS/DOLBY
17: HDMI 4K@60Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
18: DVI 1280x1024@60Hz, Audio None
19: DVI 1920x1080@60Hz, Audio None
20: DVI 1920x1200@60Hz, Audio None
21: HDMI 1920x1200@60Hz, Audio 2CH PCM/6CH PCM
22: User EDID 1
23: User EDID 2
24: EDID Passthrough
|
