Introduction
FEATURES:
• Encodes 2ch optical S/PDIF audio to a Dante® digital signal
• Decodes a 2ch Dante® digital signal to optical S/PDIF audio
• Supports: 44.1, 48, 88.2 & 96 KHz sample rates @ 16, 24 & 32 Bit
• Configurable Dante® device latency (supports 2, 3, 4, 5 or 10ms configurable using Dante® Controller)
• +6dB / -24dB input sensitivity and output gain control adjustment
• Supports AES67 RTP audio transport
• Features Class 0 802.3af PoE for powering of product from any PoE switch
• Local 12v power supply input for when network switch does not support PoE*
* PS121PH power supply sold separately
Front Panel
1
2
Connections:
DC Input - Connect to +12VDC power supply (not supplied) if device is not powered via a PoE switch
1
Dante® Audio Input/Output - RJ45 socket connects Dante® network and powers device via PoE
2
Optical S/PDIF Digital Input - 2ch optical digital audio input to Dante®
3
Optical S/PDIF Digital Output - 2ch optical digital audio output from Dante®
4
Reset Switch - Press and hold to reset device
5
Contact:
support@blustream.com.au
DA22OPT
Quick Reference Guide
Our DA22OPT has been designed to both encode 2ch
digital signal, and decode a Dante® digital signal to 2ch
is a plug & play device that is powered using PoE (Power Over Ethernet). The DA22OPT also
supports AES67 RTP audio transport.
Rear Panel
3
4
|
support@blustream-us.com
optical S/PDIF audio
optical S/PDIF
Side Panel
5
|
support@blustream.co.uk
DA22OPT
QUICK REFERENCE GUIDE
to a Dante®
audio. The DA22OPT
01
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BluStream DA22OPT
Summary of Contents for BluStream DA22OPT
- Page 1 Dante® digital signal to 2ch optical S/PDIF audio. The DA22OPT is a plug & play device that is powered using PoE (Power Over Ethernet). The DA22OPT also supports AES67 RTP audio transport. FEATURES: • Encodes 2ch optical S/PDIF audio to a Dante® digital signal •...
- Page 2 Dante products that are set up with the same sample rate. A mismatch in sample rate may stop audio from transmitting. Under the “Device Config” screen we can also adjust the latency of the DA22OPT from 2, 3, 4, 5 or 10 milliseconds. www.blustream.com.au www.blustream-us.com...
- Page 3 Web Interface Module The DA22OPT features an in-built Web GUI which can be used for control and configuration of the device. By default the device is set to DHCP, however if a DHCP server (eg: network router) is not installed the device will receive a link local address in the 169.254.xxx.xxx range.
- Page 4 Sound Bar CAT Cable Optical Audio Specifications Package Contents • 1 x DA22OPT Audio Input/Output Connectors: 1 x RJ45, female (100 Mbps Dante® network) 2 x Optical Toslink (S/PDIF) • 1 x Quick Reference Guide Casing Dimensions (L x W x H):...
