Introduction

FEATURES:
• Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
• Features 1 x HDMI, 1 x USB-C, and 1 x DisplayPort™ input on the HDBaseT™ Transmitter with manual or auto source
selection
• Features a local HDMI input on the HDBaseT™ Receiver for connection of a source device local to the display
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p up to a distance of 70m over a single CAT cable
• Supports all known HDMI audio formats including Dolby TrueHD, Atmos, and DTS-HD Master Audio transmission
• Supports USB Type C up to 4K UHD 60Hz 4:4:4* (DP1.2 with 60W charging capability)
• Supports DisplayPort™ up to 4K UHD 60Hz 4:4:4, 4K 30Hz 4:4:4 DP1.2
• Audio breakout to analogue L/R audio** and Coaxial digital (S/PDIF) outputs concurrently
• Supports Bi-directional PoC to power extenders from either Transmitter or Receiver end
• Bi-directional IR pass-through
• Auto display on / off feature allowing control of display at the HDBaseT™ Receiver via CEC, RS-232, or Relay
• Web interface module for control and configuration of the HEX70HDU-KIT
• Control via front panel, IR, RS-232 and TCP/IP
• Advanced EDID and HDCP management
*USB-C video support is limited to 4K 60Hz 4:2:0 when charging feature is activated by the source device
**Analogue audio breakout supports 2ch PCM only
contact:
support@blustream.com.au
Our HEX70HDU-KIT extender kit is an industry leading 4K HDBaseT™ multi-format
solution delivering HDMI, USB-C and DisplayPort™ up to lengths of 70m at 1080p
(40m at 4K 60Hz 4:4:4) over a single CAT cable.
The HEX70HDU-KIT provides enhanced features including local HDMI input on
the HDBaseT™ Receiver for additional source input, web GUI for control and
configuration, auto display control, audio breakout, bi-directional IR pass-
through, and EDID management.
The HEX70HDU-KIT has multiple control options including buttons on both TX
and RX units, IR, RS-232 and TCP/IP.
|
