Table Of Contents - BluStream HEX70HDU-KIT User Manual

Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions care-
fully before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
Surge Protection Device
Recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc.
Use of surge protection systems is
highly recommended in order to
protect and extend the life of your
equipment.
02
Contents
Introduction
Features
TX Panel Description
RX Panel Description
USB-C Functionality
Front Panel LED's and Auto Switching
EDID Control
Automatic System On/Off Control
Relay Control
Infrared (IR) Control
CEC Control
Terminating CAT Cables for use with HDBT
Understanding the HDBaseT™ Status LED's
Schematic
Web GUI Control
IR Commands
RS-232 Config & Telnet Commands
Specifications
Package Contents
Maintenance
Certifications
