Troubleshooting Flowcharts
Figure 3-68: Troubleshooting Flowchart - 9
Existing FlexPay
MDE-4784D FlexPay™ Encrypting PIN Pad Start-up and Service Manual · December 2011
EPP
Yes
Ensure that there is
nothing physically
inhibiting the FlexPay EPP
from seating properly onto
the bracket or dispenser
If all the
above is
verified,
replace
Flex Pay EPP
BEGIN
FlexPay EPP 2.1
loses Activation
(Shows on RKL Tool)
Are all 4
No
screws tight?
Yes
Is FlexPay EPP
mounted on
bracket/dispenser
correctly?
Yes or No
Remove FlexPay
EPP from bracket/
dispenser
and reinstall. Ensure
that you tighten all 4
screws
Does the
message still
indicate "Not
Activated"?
No
Reactivate
FlexPay EPP
Complete WRMA Part Card,
attach to bad FlexPay EPP
and replace FlexPay EPP
Start-up and Service
Tighten all 4
screens and
check again
Test Debit
