Using the FlexPay EPP Mapping Tool

Sending the Key Map File to the FlexPay EPP

To send the required key map to a FlexPay EPP, proceed as follows:
Connect the laptop that contains the FlexPay EPP Mapping Tool application to a FlexPay EPP
1
on the dispenser using the programming connector. Refer to
FlexPay EPP"
Open the FlexPay EPP Mapping Tool application.
2
Click Open Existing Map to select a key map file. The Open window appears.
3
Note: The button layout of the auxiliary keys cannot be changed when Open Existing Map is
Figure 3-51: Selecting the Key Map File
Select the required key map file from the aut\ directory and click Open.
4
Note: If the required key map file does not exist in the aut\ directory, change the directory to
The name of the key map file selected appears in the "Map File" field.
5 Select File and Send key map to save a copy and send the map to the FlexPay EPP. The Save
As window appears.
Enter a new file name to save a copy of the key map file, if required.
6
Click Save. A dialog box appears.
7
MDE-4784D FlexPay™ Encrypting PIN Pad Start-up and Service Manual · December 2011
on page 25.
selected.
find the required key map file.
Start-up and Service
"Connecting a Laptop to the
Page 51
