Start-up and Service
11
In the Diagnostic Mode, run a Keypad Test to check all keys. For instructions, refer to
"Performing the Keypad Test"
Exit the Diagnostic Mode. For instructions, refer to
12
Diagnostic Card"
Run a debit transaction to verify proper operation.
13
Close the Payment door.
14
New Features in FlexPay EPP 2.1 (M10662B001)
The FlexPay EPP 2.1 has the following new features when compared to FlexPay EPP 1.3:
• There are four Activation switches (two per side) that are used to activate the PIN Pad for
Figure 3-57: FlexPay EPP 2.1
• The Wheelchair/ADA symbol has been removed from the Help key. The ADA key must
• The Red button that was present on the left hand side of the FlexPay EPP has been
• FlexPay EPP 2.1 has a new part number: M10662B001.
• When FlexPay EPP 2.1 is released, FlexPay EPP 1.3 will be sold as a spare only.
• All FlexPay EPPs (2.1) will have a yellow sticker on the rear side (see
Figure 3-58: Yellow Sticker on the Rear Side of FlexPay EPP 2.1
Yellow
sticker
Page 60
on
page
19.
more security (see
Figure
be programmed as an auxiliary key.
removed.
MDE-4784D FlexPay™ Encrypting PIN Pad Start-up and Service Manual · December 2011
New Features in FlexPay EPP 2.1 (M10662B001)
on
page
18.
"Exiting Diagnostic Mode Using
3-57).
Activation switches
Figure
3-58).
