1) Gas data
1a) Gas type
1b) Test point pressure
1c) Nominal gas consumption
2) Model
3) Personalization
4) Manufacture s data
PROCEDURE FOR REQUESTING SERVICE
Contact one of the authorised service centres for all
requirements.

TECHNICAL INFORMATION

The cooking plate, referred to from now on as the ap-
pliance, is designed and produced for cooking foods
in direct contact with the plate in the professional ca-
tering sector.
Main Parts
A)Cooking plate: in stainless steel.
B)Fume exhaust vent (Type A): for removal of the
fumes generated by the burner.
C)Burner control knob: controls the supply of gas to
the burner.
D)Piezoelectric ignition: lights the burner.
E)Inspection hatch: for accessing the pilot light.
F)Gas supply connection: for connecting the gas sup-
ply.
G)Flue Deflector: acts as heat shield for rear wall that is
combustible. ( See pag. 14).
TECHNICAL DATA
See Connection card at back of manual.
GENERAL DESCRIPTION OF THE APPLIANCE
5) Serial number
6) Test gas indicator frame
7) Application
8) Country
When requesting service, state the data provide on
the nameplate and provide a description of the fault.
