AMI Codes-II CC
Program List and Explanations
2.2.1.4
2.2.1.5
2.2.2
2.2.2.5
2.2.3
2.2.3.1
2.3 Sample
2.3.1
A-96.250.581 / 181120
Cal. History: Shows the diagnostic values of the last calibrations.
Number: Counter for the calibrations
Date, Time: Date and time assigned to a number.
Factor fc: Factor fc is the multiplier applied to the slope of the free
chlorine calibration line. The ideal factor is 1.00.
Factor tc: Factor tc is the multiplier applied to the slope of the total
chlorine calibration line. The ideal factor is 1.00
Ver. History: Shows the verification values of the last verifications:
Number: Calibration counter.
Date, Time: Date and time of the calibration.
Absorbance: Measured absorbance of the reference kit.
Reference value: True value of the reference kit according to label.
pH Electrode: Only if pH option is installed.
Current Value: Shows the actual measured pH value.
Raw value: Shows the actual electrode voltage in mV.
Cal. History: Shows the calibration values of the last pH sensor cal-
ibrations. Offset in mV and slope in mV/pH.
Typical offset of pH electrode:
Max. tolerated offset:
Typical slope of pH electrode:
Max. limits:
Miscellaneous:
Case Temp: Shows the current temperature in °C inside the transmit-
ter.
Sample ID: Shows the identification assigned to a sample. This
identification is defined by the user to identify the location of the
sample.
Sample Flow: Shows the actual sample flow in B/s (bubbles per
second). Sample flow must be above 5 B/s.
Raw value: Shows the raw value of the sample flow in Hz.
Temperature: Only if pH option is installed.
Actual sample temperature in °C and in Ohm (NT5K)
<  30 mV.
<  60 mV
55–65 mV/pH unit.
40–65 mV/pH
