Swan Analytical Instruments AMI Codes-II CC Operator's Manual page 107

AMI Codes-II CC
Default Values
11.
Operation
Sensors
Alarm Relay
Relay 1 and 2
Input
Logger
Display
Installation
Sensor
Signal Output
1 and 2
A-96.250.581 / 181120
Default Values
Note: The parameter Cleaning is only visible if an optional
Cleaning Module is connected to the AMI Codes II.
The parameters pH and temperature are only visible if the pH
option is installed.
Filter Time Const.:........................................................................ 30 s
Hold after Cal.:........................................................................... 120 s
Interval fac: ................................................................................ 5 min
Interval tc2 ............................................................................... 20 min
default pH: (If pH option is not installed)......................................7 pH
.........................................................................same as in Installation
.........................................................................same as in Installation
.........................................................................same as in Installation
Logger Interval:.............................................................. Event Driven
Clear Logger: .................................................................................. no
Display 1; Line 1 .......................................................Free av. chlorine
Display 1; Line 2 ......................................................... Total chlorine 2
Display 1; Line 3 ..........................................................Calc. comb. cl.
Display 2; Line 1 ......................................................... Total chlorine 1
Display 2; Line 2 ....................................................Calc. dichloramine
Display 2; Line 3 ......................................................... Total chlorine 2
Dimension:................................................................................... ppm
Interpolation: ................................................................................... no
Ref. Verification:......................................................................... 0.255
Standard: Standard 1:.............................................................7.00 pH
Standard: Standard 2:.............................................................9.00 pH
Cleaning............................................................................ 2 Solutions
Parameter: ...............................................................Free av. chlorine.
Current loop: ........................................................................4 - 20 mA
Function: .................................................................................... linear
Scaling: Range low: ............................................................. 0.00 ppm
Scaling: Range high:............................................................ 5.00 ppm
Scaling: Temperature: Range low:........................................... 0.0 °C
Scaling: Temperature: Range high: ........................................ 50.0 °C
Scaling: pH: Range low: .........................................................0.00 pH
Scaling: pH: Range high: ......................................................14.00 pH
107
