Swan Analytical Instruments AMI Codes-II CC Operator's Manual page 60

AMI Codes-II CC
Maintenance
Cleaning
60
1 Switch off the instrument according to instructions in
eration for Maintenance, p.
2 Remove the constant head cover [A].
3 Remove the constant head tube [C] from the flow cell block.
4 Pull the overflow tube [B] out of the flow cell block [D].
5 Clean all acrylic parts with a soft brush (bottle cleaner) and soapy
water.
6 Remove lime deposits with a common household deliming agent
with standard concentrations.
7 Rinse the parts carefully with clean water.
48.
A-96.250.581 / 181120
Stop of Op-
