Swan Analytical Instruments AMI Codes-II CC Operator's Manual page 65

AMI Codes-II CC
Maintenance
6.10.2 Replace the Reagent Tubes
Tube
numbering
Nr. from
1 Pump outlet rear frame
2 Pump outlet middle frame
3 Reagent container (M)
Oxycon on-line DPD
4 Reagent container (N)
Oxycon on-line Buffer
5 Reagent container (O)
Oxycon on-line KI
6 Valve block connection 6
7 Pump outlet front frame
A-96.250.581 / 181120
Q
1 2
3
4
6
3 4 5
M N O
1
2
7
6 6
7 7
5 5
to
Flow cell block, connection 1
see Flow cell block side view Q
Flow cell block, connection 2
see Flow cell block side view Q
Pump inlet rear frame
Pump inlet middle frame
Valve block connection 5
Pump inlet front frame 6
Valve block connection 7
Level
