Swan Analytical Instruments AMI Codes-II CC Operator's Manual page 20

AMI Codes-II CC
Product Description
2.2.
20
Instrument Overview
A
B
C
D
E
F
A Panel
B
Transmitter
C Peristaltic pump
D
Reagent Oxycon on-line DPD
E Reagent Oxycon on-line Buffer
F
Reagent Oxycon on-line KI
G Temperature sensor
H pH sensor
I
Constant head
G G
H H
I I
J J
K K
L L
M M
N N
O O
P P
Q Q
R R
J Flow regulating valve
K
Sample inlet
L Valve 1 (Photometer)
M
Valve 2 (KI dosing)
N Inlet filter
O Photometer
P
Air bubble detector
Q Constant head drain
R
Photometer drain
A-96.250.581 / 181120
