1. Overview

MODUL CapnoVol
6 Green charging
indicator (battery
charging)
5 Display
LIFE-BASE Mini II
Stand-alone
LIFE-BASE Micro
12 Luer lock elbow adapter
20 Connection for CO extraction tube
2
19 Connector for BiCheck flow sensor
18 Sensor cable
17 Connector for sensor cable
16 Water filter
12 Luer lock elbow
adapter
4
Overview
1 Red alarm indicator
2 IR interface
4 Operating key
LIFE-BASE II
LIFE-BASE III
11 Inlet for
oxygen duct
10 Intake opening
for respiratory gas CO
measurement
15 CO
extraction tube
2
3 Outlet for
oxygen duct
LIFE-BASE II
LIFE-BASE III
LIFE-BASE Mini II
LIFE-BASE Micro
stand-alone
8 Connection for BiCheck flow sensor
2
9 Connection for power supply
13 BiCheck flow sensor
14 Clip for securing
patient tube
system
22 Power supply cable 12 V
4 Operating
key
7 On/Off key
21 Tube protection sleeve
