Weinmann Emergency MODUL CapnoVol Servicing And Repair Instructions page 18

• PC with Windows XP operating system or
higher, free serial port and installed calibration
software WM 22919.
1. Start calibration software WM 22919.
2. Open the device as described in "7.2 Open
the device" on page 23.
3. Push water filter onto the intake opening for
16
respiratory gas CO
2
4. Push the latch and take the connector of the
CAP 100 internal connecting cable off
connection X5 of the main circuit board.
5. Connect the CAP 100 internal connecting
cable to the CAP 100 external test connecting
cable.
6. Connect the CAP 100 external test connecting
cable to level converter WM 22825
7. Plug power supply WM 22825 into a socket.
the pump must be audibly
Requirement:
running.
8. Push CO absorber WM 22172 onto water
2
filter at the intake opening for respiratory
16
gas CO measurement
2
9. Follow the instructions in the calibration
software (see Help file in calibration software
WM 22919).
Note
The flow rate supplied should be at approx.
0.5 l/min.
10. Disconnect the external test connecting cable
for the level converter from the CAP 100
internal connecting cable.
5.5.2 After successful calibration
1. Shut off the gas cylinders.
2. Take the CO absorber off
2
MODUL CapnoVol.
3. Close the device as described in Section "7.3
Close the device" on page 24.
4. Test the device (see "4. Test the device" on
page 8).
18
Servicing
measurement .
10
.
10
CAP 100 external test
connecting cable
X5
10
16
CO absorber WM 22172
2
CAP 100 internal
connecting cable
