7.5 Replace Nafion tube

Materials and tools required
• Side nippers
• Cable tie
1. Open the device (see "7.2 Open the device"
on page 22).
2. Undo the cable tie.
3. release Nafion tube
Carefully
white connecting pieces
4. Replace Nafion tube
5. Secure the cables of the main circuit board
and CAP 100 circuit board with a new cable
tie .
33

7.6 Replace main circuit board and/or CAP 100 circuit board

Materials and tools required
• ESD workstation
• Slot screwdriver, insulated, size 1
• Phillips screwdriver, size 2
• Open-ended spanner WAF 15 mm
• Ring spanner WAF 14 mm
• Tubular hexagon box wrench 5.5 mm
• Side nippers
• Cable tie
• Pointed pliers
7.6.1 Remove components
1. Open the device (see "7.2 Open the device"
on page 22).
2. Take the connector of battery
on the main circuit board and take the battery
out of the device.
3. Undo the nut of the connection for BiCheck
flow sensor and push the connection inside
8
the device.
4. Fix Capno connection adapter
using an open-ended spanner.
from the
58
58.
off terminal
30 X1
in position
43
24
X5
X1
58
43
24
X1
30
43
Repair information and repair instructions
Cable tie
33
9 8
