4. Take the display illumination cable connector
off the main circuit board.
5. Take connector
off the main circuit board.
X8
6. Undo the ribbon cable from latch
pull up the top part of the latch. You can then
pull out the cable.
Warning!
Ensure that the main circuit board and the
cable are not damaged in the process.
7.3 Close the device
Materials and tools required
•
ESD workstation
•
Phillips screwdriver, size 2
1. Push the ribbon cable into latch
circuit board
and then push the top part of
31
the latch back in.
2. Push connector
onto the main circuit board
X8
.
31
3. Push the display illumination connector onto
main circuit board
31
4. Position the insulating cover back inside the
device over the main circuit board and CAP
100 circuit board and glue it firmly in place
with Loctite WM 14920.
5. Carefully put top part of housing
bottom part of housing
6. Turn the device over and screw the 4
screws
into the bottom part of the housing.
50
7. Test the device (see "4. Test the device" on
page 8).
: to do so,
X9
on main
X9
.
back onto
23
.
24
X9
X8
X9
X8
Insulating
cover
23
50
24
Repair information and repair instructions
Display illumina-
tion cable
23
Display illumi-
nation cable
24
50
23
