ETC sensor+ CEM+ Configuration Manual page 53

Step 3:
Step 4:
Pull handle while pressing
Replace a CEM+ Module:
Step 1:
W A R N I N G :
Step 2:
Step 3:
5
Service
Press the "eject" symbol on the right end of the spring-loaded handle and grab
the other end of the handle, pulling it until it is perpendicular to the face of the
CEM+. The CEM+ will be gently pushed out of the rack as you move the handle.
Pull the CEM+ straight out.
ETC CEM+ R 1/ 6 G 9
Firmly press the new CEM+ module into the correct slot by pressing on the
outside edges until you feel the connections seat (the module face will be flush
with the other modules).
Do not press on the center of the CEM+ to insert it into a rack. Doing so may
result in damage to the CEM+.
Close and lock the Sensor rack door before applying power.
ONLY if directed to do so by an ETC-authorized service representative, transfer
the configuration files/information to your new CEM+.
Press here to insert.
E
[Rack OK]
. Press here to get handle.
