configuration for the local CEM+. The NoConfig menu has no login requirements and
anyone has access to these menu items.
S e t G r o u p / R a c k
The Set Group / Rack menu allows you to set the rack number of your local rack and the
group number it belongs to. It also provides a place to set the network information (IP
address, subnet mask and gateway IP). This should be done before creating a
configuration.
G e n e r a t e D e f a u l t s
The Generate Defaults menu allows you to create an initial configuration for your local rack.
You can set your group and rack numbers along with rack type and dimmer information.
However, you can only add multiple racks of the same type. Additional racks or rack types
must be added later via the Add Racks menu item. For the face panel menu see
[Power], page 14
• Rack Types: SRxx is the U.S. style perminent installation rack and SPxx is the U.S.
style type of portable rack (including touring racks). ESRxx and ESPxx are for
European installation racks and portable racks respectively. In all cases, the "xx"
number is determined by the number of slots in the rack for modules (not the number
of dimmers).
S e l e c t C o n f i g
After selecting this function, you will be prompted with the name of the rack you want to get
the configuration from. Options will include Server which refers to an FTP server if one is
configured on your lighting network. Please see the section
information about setting up an FTP server for use with CEM+. It will then transfer the
configuration to the local CEM+. After the transfer is complete, you will get a confirmation
or error message for the transfer.
S e t u p N e t w o r k
The Setup Network menu allows you to configure the IP addresses in the network table of
the local CEM+. These are the IP addresses that the local CEM+ will use to communicate
with other CEM+s in the group. Making changes in this menu does not change the actual
IP addresses of other CEM+s, just what this CEM+ thinks they should be. You can also
enable or disable a selected CEM+ network entry in the table. This will determine if the local
CEM+ will attempt to share information with that unit. Lastly, you can enable or disable
whether the local CEM+ will look for a bootp server for IP address information. Currently,
it is strongly recommended that you leave the bootp setting disabled.
A b o u t
The About menu provides status information about the dimmers, racks, network and Group.
Everything in the About menu is accessible by all users. No settings can be changed within
the About menu. Data can only be viewed.
About Dimmer provides information about a selected dimmer, including recorded and
actual loads, the dimmer type, curve and maximum voltage. You can also view the current
output level, the source of that level, and the dimmer's location.
R a c k G e n e r a l
The Rack General menu provides the current ambient temperature and air flow status of
the selected rack. It also displays the rack type, the air filter cleaning reminder setting, and
the number of hours until the air filter cleaning reminder is due.
R o o m s & P r e s e t s
About Rooms & Presets provides information on the room and preset settings for the rack
you are currently browsing.
2
Basic Navigation
and for the web interface see Add Racks, page 21.
FTP Server, page 45
Add Rack
for more
8
