F i l e U p l o a d
The File Upload web page is where you send
either a configuration file or a software file to the
CEM+ you are logged into. The CEM+ looks at
the file being sent to automatically handle the file
type or part of the configuration file.
L o a d M a n a g e m e n t
From this webpage, you can record, check, and clear load information for Advanced
Feature modules (such as the D20AF).
For the functions on this page to work properly, you must turn on Load Errors for each of
the advanced features (AF) dimmer modules you want to use in load management. Please
see "Configure Dimmers", page 22
dimmer.
31
for more information about enabling load errors for a
Performs a Load Check by
running the levels of dimmers
up & down checking for
differences between recorded
and actual loads.
Record Loads runs the
dimmers levels up & down to
record the loads.
You must turn on (check)
Load Errors for Record
Loads to work properly. Just
turning on AF does not turn on
Load Errors by default.
Clear Loads will delete the
previously recorded loads.
Level & Source display the
current dimmer level and the
control source for the dimmer.
Shown above, dimmers 101-
106 are controlled by the
Lobby preset.
