the fan to shut off if there have been no dimmer levels sent to that rack in 15 minutes. When
levels are sent to dimmers in the rack, the fan will start up automatically. The fan will always
run for 15 minutes following a reset of the CEM+.
G e t C o n f i g [ Power]
After selecting this function, you will be prompted with the name of the rack (1-16) you want
to get the configuration from. One option is Server which refers to an FTP server if one is
configured on your lighting network. Please see the section
information about setting up an FTP server for use with CEM+. It will then transfer the
configuration to the local CEM+. After the transfer is complete, you will get a confirmation
or error message for the transfer.
S e n d C o n f i g t o A l l [ Power ]
Upon pressing
configuration out to all of the other CEM+s in the group and to the FTP server if one is
configured for the group. Please see the section
about setting up an FTP server for use with CEM+.
D e l e t e A l l R a c k s [Power ]
Immediately after pressing
rack (the one you are logged into), but does not clear everything from the CEM+. The
network settings, and custom PIN for the face panel remain intact.
N e t w o r k D e f a u l t s [Power ]
Pressing
masks, and gateway IPs) to their defaults for the current Group and Rack settings.
G r o u p [ U s e r ] [ P o w e r ]
The Group menu includes menus for recording loads, naming the group, setting the
preferred units for temperature reporting, and language and login settings. The Group
menu is available only to those logged in at the User level.
R e c o r d L o a d s [ User ]
The Record Loads menu is used to record the loads on each dimmer. This is useful in
Advanced Features systems where load reporting is desired.
N a m e G r o u p [ User ]
The Name Group menu allows a User to set the name of the Group. Names are
alphanumeric and can be up to 20 characters long (not all 20 characters will be visible on
the LCD).
S e t L a n g u a g e [ User]
The Set Language menu allows a User to set the language of the user interface.
A m b i e n t T e m p T y p e [ User]
The Ambient Temp Type menu allows a User to set temperature reporting as either
Fahrenheit or Celsius.
S e t L o g i n T i m e - o u t [ User]
The Set Login Time-out menu allows a User to set the time after which the CEM+ will
automatically log the current user out and return to the default access level as set in the
Group configuration. The time-out is based upon inactivity at the keypad.
Set P I N [ User ] [ Power]
The Set PIN menu allows you to set the PIN for your current login access level and below.
15
for this function, you will immediately send the locally contained
, this operation clears the rack configuration from the local
on this screen will immediately reset your network table (IP addresses, subnet
FTP Server, page 45
FTP Server, page 45 for more information
Sensor+ Dimming System User Manual
for more
