preheat. Preheat settings are not available to the User level login.
• DC Output Prevent: this setting offers protection on selected dimmers for loads that are
sensitive to DC buildup, which can occur under certain conditions when positive and
negative half-cycles become uneven.
• Inrush Protection: this setting protects against large voltage increases in a single AC
cycle. This protection is useful for high-wattage loads that may cause nuisance tripping
of circuit breakers and to limit peak currents in wiring and switchgear. This protection
is particularly useful on RCD/GFCI protected circuits. Settings for inrush protection
include: Instant, 100mS (for loads up to 10A), 300mS (for loads up to 25A) and 500mS
(for loads of 50 or 100A).
S e t T h r e s h o l d [ Power]
The Set Threshold menu allows a Power User to set a dimmer or a range of dimmers to
come on at a specific control level.
S e t M a x S c a l e V o l t a ge [ Power]
The Max Scale Voltage menu allows a Power User to set a dimmer or a range of dimmers
to a maximum output voltage that is the top (100% control) of the scaled output of that
dimmer.
S e t M i n S c a l e V o l t a ge [ Power]
The Min Scale Voltage menu allows a Power User to set a dimmer or a range of dimmers
to a minimum output voltage that is the bottom (1% control) of the scaled output of that
dimmer. The dimmer will switch on to an RMS output voltage of Min Scale Voltage when
the control level reaches the value set for threshold.
A s s i g n D i m t o R o o m [ Power]
The Assign Dimmer to a Room menu allows a Power User to set a dimmer or a range of
dimmers to a specific room for use with recording presets. A dimmer can only be assigned
to a single room at a time. There are four (4) rooms available and all dimmers default to
being assigned to Room 1.
A d v a n c e d F e a t u r e s [ Power]
The Advanced Features menu allows a Power User to set Advanced Features (on/off),
Report Load Errors, AF Sensitivity, and AF Reaction Time for a dimmer or range of
dimmers.
• Advanced Features (on/off): additional feedback from a dimmer that provides load
recording/reporting and advanced error reporting including a breaker trip, module
removed, load changes, dc output and SCR failures.
• Report Load Errors (on/off): allows for messages to report load changes once initial
loads have been recorded for a dimmer.
• AF Sensitivity (1 to 10): defines the resolution of the advanced features sensitivity in
reporting load changes. One (1) is the most sensitive/highest resolution setting and the
default is 5. AF sensitivity is based on a percentage of the recorded load.
• AF Reaction Time (5 to 60 seconds): this setting defines the hysteresis for an advanced
feature error. The error must be present for the minimum set in the AF Reaction Time
before an error will be reported.
D i m m e r C h e c k [ User]
The Dimmer Check menu allows a User to set an output level and then step through
dimmers at a selected starting point.
