C h a p t e r 3
Sensor+ Connect Web Interface
Overview
This section covers
functions and configuration
of the CEM+ and Sensor+
Connect that are available
to the Guest and User and
Power User login levels.
The web interface is a
series of web pages intended to give you easier access to all of a CEM+ module's features
and settings. This section will provide you screenshots of various key pages and provide
further insight into how to use them. Setup and configuration procedures are covered in
"Chapter 4: CEM+ Configuration Procedures" on page 32.
For a complete web interface site map outline, please see
Connect Site Map" on page 69.
The CEM+ module contains a web server that delivers graphical web pages for you to use
during system configuration. The Sensor+ Connect Web browser interface can be used
instead of the direct buttons on the CEM+ module itself. You can use an Ethernet-capable
PC connected to the ETCNet2 network and running Windows 2000 or XP and Internet
Explorer 6 or later to browse into any of the Sensor+ racks on the network. Any changes
made in the web interface are not communicated to the CEM+ until you send that
information by clicking Save Changes on that page.
If you are using an Emphasis Control System running version 1.8.0 software or later, there
is a command in the WYSILink menu that automatically opens a browser window and
connects to Sensor+ racks.
3
Sensor+ Connect Web Interface Overview
User Level
Default
Guest
User
Power User
Edit Tabs
Navigation Frame
Login Password
[empty field] [empty field]
guest guestpass
user userpass
power powerpass
See "Appendix E: Sensor+
Logout
button and
user level
Edit Frame
18
