Delete All Racks [Power] - ETC sensor+ CEM+ Configuration Manual

Step 6:
Step 7:
D e l e t e A l l R a c k s [ P o w e r ]
Step 1:
Step 2:
•
•
Step 3:
•
•
This operation clears the rack configuration from the local rack (the one you are logged
into), but does not clear everything from the CEM+. The network settings, and custom PIN
for the face panel remain intact.
4
CEM+ Configuration Procedures
• After clicking Install, the software will be
uploaded to the CEM+. While the software
is being sent to the CEM+, the browser will
no longer respond. After several minutes,
there will be a pair of errors indicating that
the CEM+ is done transferring the file and is
now installing the software (and no longer
communicating with Internet Explorer which
is what causes the errors).
After seeing the errors, it is safe to clear the
errors (click OK) and close Internet Explorer.
• The following screens will be seen on the face panel display during software
installation:
Loading New SW
Please Wait...
Installing Software
<various messages>
Loading SW For
Dimming Processor
Loading SW For
AF Card
ETC CEM+ R 1/ 4 G 1
[Rack OK]
Repeat for any remaining CEM+s in the system.
Login as a Power User
Delete the config from the local rack (the one you are logged into).
[Web] Racks & Dimmers>Add Racks>Delete All Racks
[FP] Rack>Delete All Racks
Send the local rack's configuration to the other racks. This will send the
"noconfig" configuration to the other CEM+s in the group and effectively delete
their configuration as well.
Configuration>File Transfer>Backup
[FP] Rack>Send Config to All
While the software is being
downloaded.
While the individual components
are being decompressed and
installed.
While the CEM+ reboots with the
CEM+
new software.
1.0.2
While theCEM+ transfers some
software to the dimming engine.
While the CEM+ transfers some
software to the Advanced
Features (AF) cards (if installed).
Installation is complete. The
CEM+ returns to its normal
resting display.
34
