A d d R a c k s
This page is where you add racks to your configuration.
To change the rack and module types to the European models, click the 240V check box.
After checking 240V, you must click Save Changes before you will see the available rack
and module types change to European (ESR/ESP) models. Clicking Save Changes the
first time after the 240V check box has been altered (checkmark vs. no checkmark) will not
add a rack to the group.
R a c k #
S t a t u s
This page displays the individual rack's power information, the dimmers' control source and
current intensity level.
Displays which rack's info
you are viewing which
may be different from the
rack you logged in to.
21
First dimmer of the
first added rack.
Enable Advanced
Features for added
racks.
240V changes the available rack & module
types to European models. (Read below)
Set initial patch
mode.
Set ambient
temperature alarm.
Set the default
module type
Set the dimmer
balancing type
