Netw ork
About Network provides the network settings for the currently selected rack. You can view
the settings for any rack in the Group.
R a c k D a t a
About Rack Data provides status information for the DMX and EDMX inputs for any rack in
the Group.
R a c k P o w e r
About Rack Power provides status information for the line feed power and the voltage
headroom settings for any rack in the Group.
Identify Rack
Identify Rack flashes the LCD and buttons on the face panel of the selected rack.
G r o u p
About Group provides the software version currently installed in the racks, the status of the
Panic state and the name of the Group.
R a c k A d d r e s s
About Rack Address provides the DMX A and B starting addresses for each rack in the
Group.
L o g i n
The Login menu is where you enter the PIN number for the user level you want to access.
Guests need no PIN to view the menu items accessible to them. You will need to enter a
four-digit PIN to gain access to features that are restricted to higher user levels. Enter 2222
for User level access and 3333 for Power User level access. Use
the digits and use
P r e s e t s
The Presets menus are used to activate and deactivate Presets at the rack. If you are
logged in at the User level, you can also record and modify Presets from the CEM+.
There are four available Rooms and 128 available Presets in a single Group. A Room is a
way of grouping dimmers - such as "Lobby" or "Auditorium". An individual Preset can only
control dimmers assigned to the same Room. For example, a Preset with dimmers
assigned to the Room named "Lobby" cannot also control dimmers in the Room
"Auditorium".
Presets can also be assigned Priority. Priority is a function of ETCNet2 that defines how
various sources of control interact with dimmers. The default priority for controllers on the
network is 10. When controllers share the same priority level, a single dimmer assigned to
those controllers will output the highest level it receives. If the controllers are at different
priorities, the highest-priority controller (lowest priority number - a priority of 1 wins versus
a priority 10) will win and the dimmer will output the level sent by that controller.
A c t i v a t e P r e s e t
The Activate Preset menu allows you to activate a selected preset.
D e a c t i v a t e P r e s e t s
The Deactivate Preset menu allows you to deactivate a selected preset.
C l e a r P r es e t s [User ]
The Clear Presets menu allows a User to delete a selected preset.
9
to enter the set digit.
and
Sensor+ Dimming System User Manual
to scroll
