| SPONGE-JET 70P 70E USER MANUAL
8
INSTALLATION AND STARTUP (CONTINUED)
4) When lifting unit, use hooks or straps around shipping lugs. Utilize properly
rated lifting hooks and straps; to determined proper rating refer to specifica-
tion section under the unit model number. This will help avoid possible dam-
age or injury (Figure 2).
Figure 2
70E On/Off
2-Pole Switch
5) If lower frame spout must be rotated into proper position, this can be done
by removing V-clamp ring. (See screen changing section for proper steps for
clamp ring.)
6) Upper spacing frame spouts can be rotated by removing V-clamp ring. (See
screen changing section for proper steps for clamp ring and screen removal
and installation.)
