6. Recommended weight settings for figure 8 are Top mobile weight on pins
numbered 1 and 2, Top fixed weight on number 1 and 2, and Bottom mobile
weight on pins numbered 5 and 6.
7. Recommended weight settings for figure 9 are Top mobile weight on pins
numbered 1 and 2, Top fixed weight on number 1 and 2, and Bottom mobile
weight on pins numbered 7 and 8.
Figure 9
Figure 8
These diagrams are general aids and should not be depended on as precise
adjustments for your application.
SPONGE-JET 70P 70E USER MANUAL |
17
