13. Whether replacing motor or variable speed pulley inspect collet, draw bolt
and motor shaft for burrs and remove them. New variable speed pulleys come
with a collet. If installing new motor, key on motor shaft is not needed. (Note:
when properly installed, pulley does not require a key to drive the unit.)
14. Before installing pulley onto shaft check to see collet, lock washer and
draw bolt are assembled properly.
FIGURE 18
Draw Bolt
Lock Washer
Collet
Variable Speed Pulley
Motor
| SPONGE-JET 70P 70E USER MANUAL
28
