5.2 BALANCE CAGES
Balance Cages - Figure 10
Top Balance Cage (with typical weight settings) Horizontal Movement
Horizontal mobile weight
(max. weights 2)
Rotation
Pins
Horizontal fixed weight
(max. weights 2)
Bottom Balance Cage (with typical weight settings) Vertical Movement
Pins
Rotation
Vertical Mobile weight
| SPONGE-JET 70P 70E USER MANUAL
18
