28. Replace variable speed pulley cover and RPM control lock side cover.
29. Install angle filler ring and gasket.
30. Replace lower spacing frame. Make sure filler ring and frame are centered
on table.
31. Install "V" clamp ring; assure nut of clamp ring bolt is on right-hand side. If
clamp ring has a quick-release over center latch, secure before tightening.
32. Clamp ring should be tapped moderately with rubber mallet during ten-
sioning to insure it will seat properly.
33. Tighten two clamp ring bolts equally to ensure even tensioning.
5.6 MOTOR & VARIABLE SPEED
PULLEY REPLACEMENT
1. Before starting Lockout/Tagout unit.
2. Remove variable speed pulley cover and RPM control lock (Motor Lock) side
cover for easier access.
3. Loosen RPM control lock (Motor Lock).
4. Mark location of motor mount to help relocate it back to desired RPM set-
ting, then crank motor in all the way.
5. Remove belt.
6. Remove variable speed pulley; loosen/remove draw bolt located on top.
7. If replacing motor, lift table off base and safely set aside. This allows full
access to all bolts, wiring and ability to safely lift motor out of place. When
lifting table, disconnect flexible grease lines.
8. Disconnect wiring at conduit box on the outside of the base.
9. Loosen nut components inside of base and pull wire through.
10. Unbolt motor from motor mount.
11. Bolt up new motor to motor mount.
12. For wiring, fish wire through nut components and tighten. Keep wire away
from moving parts.
SPONGE-JET 70P 70E USER MANUAL |
27
