- Page 1 SPONGE-JET ® 35E Recycler 50E Recycler USER MANUAL Sponge-Jet, Inc. (USA) 14 Patterson Lane +1-603-610-7950 Newington, NH 03801 www.spongejet.com SPONGE-JET 35E 50E USER MANUAL | Sponge-Jet 35P 50E User Manual - REV B / ENG...
-
Page 2: Table Of Contents
This manual represents the following models: Model: 35E Weight: 148 kg (325 lb) Model: 50E Weight: 170 kg (375 lb) English Language is Original Instructions. Translated from Original Instructions. | SPONGE-JET 35E 50E USER MANUAL... -
Page 3: Safety
Sponge-Jet will void warranty. Direct attachment, such as welding or bolting of any additional chutes or hoppers, etc., to vibrating equipment other than those supplied by Sponge-Jet, Inc. will automatically void warranty. Any connection made to unit must be flexible. - Page 4 Unit should not be climbed on. g. User is responsible for taking all necessary precautions dependent on material being screened. h. Be careful when moving. Move with help. | SPONGE-JET 35E 50E USER MANUAL...
-
Page 5: Basic Components
2 Main Rim 3 Vibratory Section 4 Safety Skirt 5 Large Particle Downspout 6 Reusable Media Downspout 7 Fine Particle Downspout 8 Pan Clamp Hook 9 Pan Clamp 10 Caster 11 On/Off Switch 12 Motor SPONGE-JET 35E 50E USER MANUAL |... - Page 6 Lower Base Assembly. 6 Lower Base Assembly Supports Main Controls, Air Motor, Vibratory Portion and Sieve Assembly. 7 Flexible Coupling Absorbs startup torque from electric motor and passes that energy up through Vibratory Portion. | SPONGE-JET 35E 50E USER MANUAL...
- Page 7 Used to prevent Pan Clamp Hook from swiveling when dismounting Pan Clamps (50E only). 3 Threaded Rod Pan Clamp Hook threads onto Threaded Rod. 4 Handle Used to secure Pan Clamp to Sieve Assembly. SPONGE-JET 35E 50E USER MANUAL |...
-
Page 8: Receipt And Inspection
- Operate unit on a sturdy, flat surface. This will assure maximum efficiency. - Vibrating parts should never come in contact with static parts of unit or its surroundings. - Check to be sure screen elements are level. | SPONGE-JET 35E 50E USER MANUAL... -
Page 9: Media Classification
DOWNSPOUT WASTE REUSABLE SPONGE MEDIA IMPORTANT: Proper separation of oversized and undersized particles from reusable Sponge Media™ abrasive is critical to reducing airborne dust and minimizing risk of clogging Sponge-Jet Feed Unit™ while blasting. SPONGE-JET 35E 50E USER MANUAL |... - Page 10 Sponge Media that do not pass through Bottom Screen exit unit via Reusable Media Downspout. Sponge Media abrasive that exit Reusable Media Down- spout can be reused in Sponge-Jet Feed Unit. Working Mix: a blend of blasted Sponge Media passed through Recycler (as reusable Sponge Media) plus a quantity of new Sponge Media added every 2-3 passes through Recycler.
-
Page 11: Electrical Requirements
Unit is equipped with a 1 HP, Single phase, 115v/230v, auto-sensing 50/60 Hz, 3450 RPM, TEFC motor, which requires 11.2/5.6 amps. Unit comes equipped with 3m (10ft) of 12 AWG supply wire. Use of extension cords are strongly discouraged. WARNING: Motor is not thermally protected. SPONGE-JET 35E 50E USER MANUAL |... -
Page 12: Normal Operation
1. Sponge Media is added through Hopper located on top of unit. 2. After connecting unit to an adequate electrical supply, activate by turning On/Off Switch to “ON”. A powerful gyrating vibration will occur. | SPONGE-JET 35E 50E USER MANUAL... -
Page 13: Advanced Operation
This weight is set by factory at zero degrees with flywheel weights. To achieve maximum amplitude, loosen with 5/16” Allen wrench; rotate weight 180 de- grees and tighten. Settings between 0 degrees and 180 degrees are available. SPONGE-JET 35E 50E USER MANUAL |... - Page 14 NOTE: Flexible Rubber Coupling is 1” (24.5 mm) thick with four (4) 1/8” (3.2 mm) thick bosses. WARNING: Never run motor with only flexible rubber coupling attached to motor flange. Failure may result in serious damage and/or injury. | SPONGE-JET 35E 50E USER MANUAL...
- Page 15 10. Attach Pan Clamps. These must be closed to secure Sieve Assembly. * *IMPORTANT: All screens must be assembled with mesh on top. Incorrect installation is an easy mistake and will cause unit to operate unsatisfactorily. SPONGE-JET 35E 50E USER MANUAL |...
-
Page 16: Routine Maintenance
IMPORTANT: This unit was greased before shipment. Add grease using 1 to 2 pumps every 40 hours of operation. If the unit has not been used for one year, add 1 to 2 pumps of grease. | SPONGE-JET 35E 50E USER MANUAL... -
Page 17: Rebuild Maintenance
5. Remove top sieve weldment. 6. Follow steps 1 through 6 of “Replacement of Top Roller Bearing” (If not already complete). 7. Loosen (2) 3/8-16 set screws - Remove Flywheel. 8. Loosen (10) 3/8-16 set screws. SPONGE-JET 35E 50E USER MANUAL |... - Page 18 16. Remove seals from top and bottom caps. 17. Clean and inspect all parts for wear; deburr all parts as required. 18. Follow steps 1 through 16 in reverse order to reassemble. IMPORTANT: Follow steps for proper alignment after assembly. | SPONGE-JET 35E 50E USER MANUAL...
-
Page 19: Notes
NOTES MODEL SERIAL SPONGE-JET 35E 50E USER MANUAL |...
