3. Housing must be cleaned, all burrs removed, and grease holes cleaned out.
4. Install a new seal in housing, seal is to be installed with writing on the seal
facing outward, away from the bearing and opening facing the bearing.
5. Lay housing face up, start bearing in as straight as possible. Apply some
pressure to outer race of bearing, NEVER PUSH ON INNER RACE, as this will
damage bearing. If bearing comes out of alignment, it can be aligned by ro-
tating bearing. Do not force bearing into alignment by pounding, as this will
damage bearing.
6. Bearing must be packed with new grease. This can be done by installing a
grease fitting into housing. Use fitting on side of housing, where relief fitting
is located. As grease is pumped in, rotate inner race until bearing is full of
grease. Remove grease fitting and reinstall relief fitting.
FIGURE 21
Bearing
Bearing Housing
Note: put the opening on
seal facing bearing
Note: put the writing on
Bearing Seal
seal facing outward
SPONGE-JET 70P 70E USER MANUAL |
31
