FIGURE 11
Variable Speed Pulley
Belt
RPM Control lock
(Motor Lock)
Minimum RPM Stop
Maximum RPM Stop
Motor Mount
Adjustment Screw
Motor
FIGURE 12
RPM Control lock
(Motor Lock)
Adjustment Screw
Crank
Crank
| SPONGE-JET 70P 70E USER MANUAL
20
